Multi-Family series

Construction

• 2 x 6 exterior walls- 16" o.c. - 8' walls
• Double top plate, single bottom plate at supporting walls
• 2 x 4 interior walls 16" o.c.
• 2 x 3 mate line walls 16" o.c.
• 1/2" drywall throughout
• Walls smooth finish primed white
• Continuous exterior wall vapor barrier
• Ceilings textured finish
• 5/12 Pitch Ranch, Two Story
• 10/12 Pitch Cape Cod Styles
• Roof truss spaced 24" O.C.
• 7/16" osb roof sheathing- 15# Felt
• CertainTeed Landmark architectural shingles, see colors
• Shingle cap ridge vent ventilation system
• Vented white soffit w/ white aluminum fascia, white drip edge
• Ranch, Two Story - 16" nominal overhang at sidewall eaves, 12" overhang at gable ends
• Cape Cod - 12" nominal overhangs sidewall eaves & gable ends
• Ice Dam

2 x 6 exterior walls- 16" o.c. - 8' walls
Double top plate, single bottom plate at supporting walls
2 x 4 interior walls 16" o.c.
2 x 3 mate line walls 16" o.c.
1/2" drywall throughout
Walls smooth finish primed white
Continuous exterior wall vapor barrier
Ceilings textured finish
5/12 Pitch Ranch, Two Story
10/12 Pitch Cape Cod Styles
Roof truss spaced 24" O.C.
7/16" osb roof sheathing- 15# Felt
CertainTeed Landmark architectural shingles, see colors
Shingle cap ridge vent ventilation system
Vented white soffit w/ white aluminum fascia, white drip edge
Ranch, Two Story - 16" nominal overhang at sidewall eaves, 12" overhang at gable ends
Cape Cod - 12" nominal overhangs sidewall eaves & gable ends
Ice Dam

Mechanical

• 200 Amp Square D-HOM 4080 panel box located per plan (Jumbo)
• Copper Romex wiring
• Door chime at front door
• Smoke- C.M. detectors per code
• Brushed nickel light fixtures
• 1 light fixture- each exterior door
• Reinforced fan box @ LR, FR, DR, BR'S w/ 6" LED ceiling light & single switch
• Flush Mount 6" LED - Hall, Foyer, Utility, Walk-in Closet, Stairwell
• Bath fans double switch (1 for light, 1 for fan)
• Attic light fixture w/ pull string
• (4) flush mount 6" LED ceiling lights in Kitchen w /(1) 6" LED @ Kitchen sink (5 total)
• 110 gas range receptacle and 220 electric range receptacle
• 110 gas dryer and 220 electric dryer receptacle
• 2 exterior GFI receptacles (1 front, 1 rear) per plan
• All Kitchen and Bath receptacles GFI
• Whole House Surge Protector Included
• Pex water line below floor stubs only- finish plumbing by others
• Ice and water refer prep
• PVC below floor waste stubs- finished 2nd story plans ran to chase

Exterior

• .42 mil Georgia Pacific D4 vinyl siding (clapboard or dutchlap available)
• Jeld-Wen Brickmould single hung windows, white, clear (grids opt.)
• 36" white 6-panel front door/ rear door ( 36" where applicable)
• Fiberglass 6-Panel Front Door and Steel 6-Panel Fire Rated Rear Door
• Brushed nickel door hardware with deadbolt
• Raised panel vinyl shutters- front door side

.42 mil Georgia Pacific D4 vinyl siding (clapboard or dutchlap available)
Jeld-Wen Brickmould single hung windows, white, clear (grids opt.)
36" white 6-panel front door/ rear door ( 36" where applicable)
Fiberglass 6-Panel Front Door and Steel 6-Panel Fire Rated Rear Door
Brushed nickel door hardware with deadbolt
Raised panel vinyl shutters- front door side

Interior

• 32" and 36" interior passage doors where applicable
• 2-panel white roman arch hollow core interior doors
• Brushed nickel hardware w/ lever handles- privacy locks MB, Baths
• White base trim and casing
• White wire coated shelving all closets- per plan
• Congoleum vinyl flooring- all wet areas, Kitchen, DR, Foyer
• 25 oz Cape Canaveral carpet w/8# pad- Living areas, BR's & Halls (per plan)
• Carpet and pad ship loose- installed by others
• Cape and Two Story - Stairs to second story receive 1/2 wall with cap
• 24', 28', 30' widths available (see plan details)
• 2 x 10 floor joists- 16" o.c.
• Double perimeter rim joists
• 3/4" tongue and groove OSB floor decking- glued and fastened

32" and 36" interior passage doors where applicable
2-panel white roman arch hollow core interior doors
Brushed nickel hardware w/ lever handles- privacy locks MB, Baths
White base trim and casing
White wire coated shelving all closets- per plan

Kitchen

• Chrome Kitchen Pullout Faucet
• 8" stainless steel Kitchen sink
• Merillat Classic Spring Valley cabinetry- see std. selections
• Soft Close, Dovetail Constructed Drawers with full extension guides
• Soft Close Cabinet Doors
• Slide out middle tray in all applicable base cabinets in Kitchen
• Lazy susan at all applicable base corner cabinet areas
• Tip out sink trays at Kitchen sink
• 36" refrigerator opening
• Ventless white range hood (other colors available)
• Switch and wire for garbage disposal
• Dishwasher wire prep - omit cabinet
• Formica post form laminate countertops with backsplash-Caspian Edge
• Bank of drawers- 1 per Kitchen area- standard
• Staggered wall cabinets (corner and tall pantry cabinet- when applicable)
• Crown molding at Kitchen wall cabinets
• Drawer over door cabinet construction

Chrome Kitchen Pullout Faucet
8" stainless steel Kitchen sink

Bathroom

• One piece white fiberglass tubs and showers per plan
• Drop in style white vanity lavs with overflow
• Single lever chrome vanity faucets
• Elongated white toilets
• Merillat Classic Spring Valley or Marlin cabinetry- see std. selections
• Formica post form laminate vanity countertops w/ backsplash-Caspian Edge
• Mirror with light at all vanity areas

One piece white fiberglass tubs and showers per plan
Drop in style white vanity lavs with overflow
Single lever chrome vanity faucets
Elongated white toilets
Merillat Classic Spring Valley or Marlin cabinetry- see std. selections
Formica post form laminate vanity countertops w/ backsplash-Caspian Edge
Mirror with light at all vanity areas
